Infusion Bags
InfuLine – PVC & EVA Infusion Bags
Infusion Bags are designed to be filled with pharmaceutical / medical solutions
InfuLine Infusion Bags are made with medical-grade soft PVC and EVA (Ethylene Vinyl Acetate) film materials. It’s highly transparent, flexible, lightweight, and provided with two separate ports for injection and infusion. InfuLine IV bags are highly compatible with all standard IV infusion and transfer sets and meet the highest ecological and drug compatibility standards.
Specifications
| Product Type | Infusion Bags |
|---|---|
| Product | Infusion Bag |
| Material | PVC (Non-DEHP) / EVA (Ethylene Vinyl Acetate) |
| Volume | 50 mL ~ 5000 mL |
| Thickness | 0.72mm, can be customized |
| Inlet Diameters | 6mm ~ 8mm, can be customized |
| Tube Length | 4cm ~ 12cm, can be customized |
| Sterility | Sterile / Non-sterile |
| Sterilization | ETO / Gamma / Steam |
| Disposable | For single use only |
| Port / Connector | Twist-off PVC Port, Injection Port, Spike Port, Plugging Devices |
| OEM | OEM available |
Features
-
Capacity: 50 mL ~ 5000 mL with one or two tubes
-
Made-up of Medical Grade Soft PVC (Non-DEHP) and EVA (Ethylene Vinyl Acetate) Films
-
Compatible to moisture / steam sterilization
-
Interval (Pitch) between stopper and twist-off is 25mm and 40mm.
-
Clear Transparency, Flexible
-
Prevent air in-take
Uses
Our IV bags are meant for primary packaging of
-
IV Solutions
-
Rehydration Solutions
-
Anticoagulant Solutions
-
Infusion / Transfusion
-
Media Culture
-
Dialysis
-
Veterinary solution
-
Urology, and other applications.
Ordering Information - Infusion Bags (PVC)
| Part No. | Description | Connectors | Package |
|---|---|---|---|
| ILPVC50 | InfuLine Infusion Bag, PVC, 50 mL | Twist-Off Port / Injection Port / Spike Port | 800 /carton |
| ILPVC100 | InfuLine Infusion Bag, PVC, 100 mL | Twist-Off Port / Injection Port / Spike Port | 800 /carton |
| ILPVC150 | InfuLine Infusion Bag, PVC, 150 mL | Twist-Off Port / Injection Port / Spike Port | 800 /carton |
| ILPVC200 | InfuLine Infusion Bag, PVC, 200 mL | Twist-Off Port / Injection Port / Spike Port | 800 /carton |
| ILPVC250 | InfuLine Infusion Bag, PVC, 200 mL | Twist-Off Port / Injection Port / Spike Port | 800 /carton |
| ILPVC500 | InfuLine Infusion Bag, PVC, 500 mL | Twist-Off Port / Injection Port / Spike Port | 500 /carton |
| ILPVC1000 | InfuLine Infusion Bag, PVC, 1000 mL | Twist-Off Port / Injection Port / Spike Port | 400 /carton |
| ILPVC1500 | InfuLine Infusion Bag, PVC, 1000 mL | Twist-Off Port / Injection Port / Spike Port | 400 /carton |
| ILPVC2000 | InfuLine Infusion Bag, PVC, 2000 mL | Twist-Off Port / Injection Port / Spike Port | 250 /carton |
| ILPVC3000 | InfuLine Infusion Bag, PVC, 3000 mL | Twist-Off Port / Injection Port / Spike Port | 250 /carton |
| ILPVC5000 | InfuLine Infusion Bag, PVC, 5000 mL | Twist-Off Port / Injection Port / Spike Port | 100 /carton |
Ordering Information - Infusion Bags (EVA)
| Part No. | Description | Connectors | Package |
|---|---|---|---|
| ILEVA50 | InfuLine Infusion Bag, EVA, 50 mL | Twist-Off Port / Injection Port / Spike Port | 800 /carton |
| ILEVA100 | InfuLine Infusion Bag, EVA, 100 mL | Twist-Off Port / Injection Port / Spike Port | 800 /carton |
| ILEVA150 | InfuLine Infusion Bag, EVA, 150 mL | Twist-Off Port / Injection Port / Spike Port | 800 /carton |
| ILEVA200 | InfuLine Infusion Bag, EVA, 200 mL | Twist-Off Port / Injection Port / Spike Port | 800 /carton |
| ILEVA250 | InfuLine Infusion Bag, EVA, 200 mL | Twist-Off Port / Injection Port / Spike Port | 800 /carton |
| ILEVA500 | InfuLine Infusion Bag, EVA, 500 mL | Twist-Off Port / Injection Port / Spike Port | 500 /carton |
| ILEVA1000 | InfuLine Infusion Bag, EVA, 1000 mL | Twist-Off Port / Injection Port / Spike Port | 400 /carton |
| ILEVA1500 | InfuLine Infusion Bag, EVA, 1000 mL | Twist-Off Port / Injection Port / Spike Port | 400 /carton |
| ILEVA2000 | InfuLine Infusion Bag, EVA, 2000 mL | Twist-Off Port / Injection Port / Spike Port | 250 /carton |
| ILEVA3000 | InfuLine Infusion Bag, EVA, 3000 mL | Twist-Off Port / Injection Port / Spike Port | 250 /carton |
| ILEVA5000 | InfuLine Infusion Bag, EVA, 5000 mL | Twist-Off Port / Injection Port / Spike Port | 100 /carton |
