2D Biocontainers
Single-Use 2D Biocontainers for Storage, Transport, and Fill & Finish Bioprocessing Applications
Ranging from 3 mL to 200 L
CellBios® offers individually leak-tested 2D Bags for consistent performance and the best assurance of supply for Bio-Pharmaceutical / Bioprocess applications. Excellent durability and toughness due to high weld strength provide sturdy and reliable performance. Flexible and puncture resistant even at very low temperatures.
2D Bioprocessing single-use containers are designed for the biotech, bioprocess, and biopharmaceutical sector for efficient fluid management of media, buffer, harvest, downstream intermediates, and drug substance/products.
The advantages of single-use biocontainers are more affordable, reduced footprint, flexibility, reduced risk of contamination, production efficiency, easy changeover, improved capacity, improved assurance of Quality, and time management.
CellBios adapts cutting-edge design strategies for making better and more efficient single-use biocontainers. Gamma Irradiated.
Single-Use biocontainers are built from multiple components assembled together to provide a better design and to meet the functional requirements.
Applications
- Buffer preparation, storage and transport
- Media preparation, storage and transport
- Cell culture / harvesting
- Mixing
- Filtration
- Separation and Purification
- Drug / product intermediates storage
- Collection of fractions
- Chromatography process
- Drug/ product intermediates storage and transport
- Product storage prior to filling
- Product transport
- Fill and Finish
- Filling bag manifold
- Waste collection
Features
- 2D Bioprocess bags are available from 3 mL to 200 L
- Impulse heat–sealing technology is used for consistent bag sealing and integral port sealing of the bag
- Excellent durability and toughness
- Exhibits superior clarity and transparency for better visibility
- Excellent gas barrier properties
- Reduce the risk of cross-contamination
- Each biocontainer is leak tested
- Suitable for long-term storage of materials at a wide range of temperatures (+60 °C to -80 °C)
Benefits
- Consistent film and materials of construction used across the entire range of 2D and 3D biocontainers
- Inert Ultra low-density polyethylene fluid contact layer
- High clarity and flexibility
- Very low level of extractables and leachables
- Compatible with a wide range of chemicals and pH
- Excellent gas barrier film material
- Animal ingredients-free material
- Transparent biocontainers for easy visual inspections of the solutions/product
- Better design to ensure faster installation
- Efficient design for ease of use, better drainage of the fluid, stability of the product during storage
- Final biocontainers assembly is done at the separate ISO 7 clean room environment
- Process capability enables the customization of the widest port and tubing choice for inlet and outlet connections
- Custom design bioconatiners are available
Connectors, Tubes and Ports
The materials of construction of the 2D biocontainers meet:
- USP 661 Physicochemical tests for plastics
- European Pharmacopoeia (Section 3.1.5)
- Japanese Pharmacopoeia (Section 61 Part 1)
- European directive 85/572/EEC for food contact plastic materials
Features
| S.No. | Description |
|---|---|
| 1 | 2D Biocontainer |
| 2 | TPE (Tube) - 3.2x6.4 mm (1/8x1/4 in.) |
| 3 | TPE (Tube) - 6.4x9.5 mm (1/4x5/8 in.) |
| 4 | Female Luer |
| 5 | MPC Coupling Insert |
| 6 | MPC Coupling Plug |
| 7 | MPC Coupling Cap |
| 8 | MPC Coupling Body |
| 9 | TPE (Tube) - 6.4x9.5 mm (1/4x5/8 in.) |
| 10 | Pinch Clamp |
| 11 | Bag Hanging Rod |
Specifications
| Tube Material | TPE / C-Flex / Silicon / EVA |
|---|---|
| Tube Length | 50 to 2000 mm (2 x 79 in.) |
| Tube Diameters (IDxOD) | 3.2x6.4 mm (1/8x1/4 in.) |
| 6.4x9.5 mm (1/4x5/8 in.) | |
| 9.5x12.7 mm (5/8x1/2 in.) | |
| 9.5x16 mm (3/8x5/8 in.) | |
| 9.5x19 mm (3/8x3/4 in.) | |
| 19x25 mm (3/4x1 in.) | |
| Connectors | MPC / MPX / Luer / Aseptic / |
| Needle-free Site |
Port Connector Configurations
| Bag Volume | Port - 1 | Port - 2 | Port - 3 | Port - 4 |
|---|---|---|---|---|
| 3 mL to 10 mL | Male Luer Lock with Cap | Female Luer Lock with Cap | - | - |
| 50 mL to 500 mL | Male Luer Lock with Cap | Female Luer Lock with Cap | - | - |
| MPC/MPX/Aseptic Connector | MPC/MPX/Aseptic Connector | - | - | |
| MPC/MPX/Aseptic Connector | MPC/MPX/Aseptic Connector | Needle-Free Site | - | |
| 1 L to 200 L | Male Luer Lock with Cap | Female Luer Lock with Cap | - | - |
| MPC/MPX/Aseptic Connector | MPC/MPX/Aseptic Connector | - | - | |
| MPC/MPX/Aseptic Connector | MPC/MPX/Aseptic Connector | Needle-Free Site | - | |
| MPC/MPX/Aseptic Connector | MPC/MPX/Aseptic Connector | MPC/MPX/Aseptic Connector | Needle-Free Site |
Ordering Information
| Part Number | Bag Volume | Bag Dimension (Width x Length) | Tube Configuration (ID x OD x Length) | Connectors |
|---|---|---|---|---|
| 2DBCA2TLN01 | 3 mL | 37x40 mm (1.5x1.6 in.) | T1: 3.2 x 6.4 x 50 mm (1/8” x 1/4” x 2”) | Luer Lock with Cap |
| T2: 3.2 x 6.4 x 50 mm (1/8” x 1/4” x 2”) | Needle-free Site | |||
| 2DBCB2TLN01 | 6 mL | 48x48 mm (1.9x1.9 in.) | T1: 3.2 x 6.4 x 50 mm (1/8” x 1/4” x 2”) | Luer Lock with Cap |
| T2: 3.2 x 6.4 x 50 mm (1/8” x 1/4” x 2”) | Needle-free Site | |||
| 2DBCC2TLN01 | 10 mL | 65x63 mm (2.6x2.5 in.) | T1: 3.2 x 6.4 x 50 mm (1/8” x 1/4” x 2”) | Luer Lock with Cap |
| T2: 3.2 x 6.4 x 50 mm (1/8” x 1/4” x 2”) | Needle-free Site | |||
| 2DBCD2TLN01 | 30 mL | 115x110 mm (4.5x4.3 in.) | T1: 3.2 x 6.4 x 100 mm (1/8” x 1/4” x 4”) | Luer Lock with Cap |
| T2: 3.2 x 6.4 x 100 mm (1/8” x 1/4” x 4”) | Needle-free Site | |||
| 2DBCE2TLN01 | 50 mL | 130x125 mm (5.1x5 in.) | T1: 3.2 x 6.4 x 100 mm (1/8” x 1/4” x 4”) | Luer Lock with Cap |
| T2: 3.2 x 6.4 x 100 mm (1/8” x 1/4” x 4”) | Needle-free Site | |||
| 2DBCF2TLN01 | 100 mL | 155x150 mm (6.1x6 in.) | T1: 3.2 x 6.4 x 100 mm (1/8” x 1/4” x 4”) | Luer Lock with Cap |
| T2: 3.2 x 6.4 x 100 mm (1/8” x 1/4” x 4”) | Needle-free Site | |||
| 2DBCG3TCCN01 | 250 mL | 152x207 mm (6x8.1 in.) | T1: 3.2 x 6.4 x 300 mm (1/8” x 1/4” x 12”) | MPC coupling insert and coupling cap |
| T2: 3.2 x 6.4 x 300 mm (1/8” x 1/4” x 12”) | MPC Body and Sealing Plug | |||
| T3: 3.2 x 6.4 x 100 mm (1/8” x 1/4” x 4”) | Needle-free Site | |||
| 2DBCH3TCCN01 | 500 mL | 165x232 mm (6.5x9.1 in.) | T1: 3.2 x 6.4 x 300 mm (1/8” x 1/4” x 12”) | MPC coupling insert and coupling cap |
| T2: 3.2 x 6.4 x 300 mm (1/8” x 1/4” x 12”) | Male and Female Luer lock with cap | |||
| T3: 3.2 x 6.4 x 100 mm (1/8” x 1/4” x 4”) | Needle-free Site | |||
| 2DBCI3TCCN01 | 1 L | 195x275 mm (7.7x10.8 in.) | T1: 6.4 x 9.5 x 300 mm (1/4” x 3/8” x 12”) | MPC coupling insert and coupling cap |
| T2: 6.4 x 9.5 x 300 mm (1/4” x 3/8” x 12”) | MPC Body and Sealing Plug | |||
| T3: 3.2 x 6.4 x 100 mm (1/8” x 1/4” x 4”) | Needle-free Site | |||
| 2DBCJ3TCCN01 | 2 L | 265x345 mm (10.4x13.6 in.) | T1: 6.4 x 9.5 x 300 mm (1/4” x 3/8” x 12”) | MPC coupling insert and coupling cap |
| T2: 6.4 x 9.5 x 300 mm (1/4” x 3/8” x 12”) | MPC Body and Sealing Plug | |||
| T3: 3.2 x 6.4 x 100 mm (1/8” x 1/4” x 4”) | Needle-free Site | |||
| 2DBCK3TCCN01 | 3 L | 305x395 mm (12x13.6 in.) | T1: 6.4 x 9.5 x 300 mm (1/4” x 3/8” x 12”) | MPC coupling insert and coupling cap |
| T2: 6.4 x 9.5 x 300 mm (1/4” x 3/8” x 12”) | MPC Body and Sealing Plug | |||
| T3: 3.2 x 6.4 x 100 mm (1/8” x 1/4” x 4”) | Needle-free Site | |||
| 2DBCL3TCCN01 | 5 L | 350x440 mm (13.8x17.3 in.) | T1: 9.5 x 16 x 300 mm (3/8” x 5/8” x 12”) | MPC coupling insert and coupling cap |
| T2: 9.5 x 16 x 300 mm (3/8” x 5/8” x 12”) | MPC Body and Sealing Plug | |||
| T3: 6.4 x 9.5 x 100 mm (1/4” x 3/8” x 4”) | Needle-free Site | |||
| 2DBCM3TCCN01 | 10 L | 420x630 mm (16.5x24.8 in.) | T1: 9.5 x 16 x 300 mm (3/8” x 5/8” x 12”) | MPC coupling insert and coupling cap |
| T2: 9.5 x 16 x 300 mm (3/8” x 5/8” x 12”) | MPC Body and Sealing Plug | |||
| T3: 6.4 x 9.5 x 100 mm (1/4” x 3/8” x 4”) | Needle Freesite | |||
| 2DBCN3TCCN01 | 20 L | 480x700 mm (18.9x27.5 in.) | T1: 9.5 x 16 x 300 mm (3/8” x 5/8” x 12”) | MPC coupling insert and coupling cap |
| T2: 9.5 x 16 x 300 mm (3/8” x 5/8” x 12”) | MPC Body and Sealing Plug | |||
| T3: 6.4 x 9.5 x 100 mm (1/4” x 3/8” x 4”) | Needle-free Site | |||
| 2DBCO3TCCN01 | 25 L | 530x720 mm (20.9x28.3 in.) | T1: 9.5 x 16 x 300 mm (3/8” x 5/8” x 12”) | MPC coupling insert and coupling cap |
| T2: 9.5 x 16 x 300 mm (3/8” x 5/8” x 12”) | MPC Body and Sealing Plug | |||
| T3: 6.4 x 9.5 x 100 mm (1/4” x 3/8” x 4”) | Needle-free Site | |||
| 2DBCP3TCCN01 | 50 L | 645x885 mm (25.4x34.8 in.) | T1: 9.5 x 16 x 600 mm (3/8” x 5/8” x 24”) | MPC coupling insert and coupling cap |
| T2: 9.5 x 16 x 600 mm (3/8” x 5/8” x 24”) | MPC Body and Sealing Plug | |||
| T3: 6.4 x 9.5 x 100 mm (1/4” x 3/8” x 4”) | Needle-free Site | |||
| 2DBCQ3TCCN01 | 100 L | 850x1150 mm (33.5x45.3 in.) | T1: 9.5 x 16 x 600 mm (3/8” x 5/8” x 24”) | MPC coupling insert and coupling cap |
| T2: 9.5 x 16 x 600 mm (3/8” x 5/8” x 24”) | MPC Body and Sealing Plug | |||
| T3: 6.4 x 9.5 x 100 mm (1/4” x 3/8” x 4”) | Needle-free Site | |||
| 2DBCR3TCCN01 | 200 L | 1000x1450 mm (39.4x57.1 in.) | T1: 9.5 x 16 x 600 mm (3/8” x 5/8” x 24”) | MPC coupling insert and coupling cap |
| T2: 9.5 x 16 x 600 mm (3/8” x 5/8” x 24”) | MPC Body and Sealing Plug | |||
| T3: 6.4 x 9.5 x 100 mm (1/4” x 3/8” x 4”) | Needle-free Site |
